Item | Specification | Unit |
| Display Size | 10.0 | inch |
| ZHUNYI Model | Z100001-P35-Y1 | - |
| LCD Module Resolution | 1560*700 | pixels |
| LCD Display Active Area | 231.43*103.8 | mm |
| LCM Display Dimension | 257.76*131.32*3.95 | mm |
| Touch Screen Dimension | - | mm |
| TFT Display Interface | LVDS | - |
| Touch Panel/PCAP Interface | - | - |
| Display View Direction | Full Viewing | - |
| Operating Temperature | -10°C~ 60°C | - |
| Storage Temperature | -20°C~ 70°C | - |
