The functional layout of touch displays on fitness equipment is designed to enhance the user experience, provide essential information, and enable easy control of the equipment. A well - planned layout can make workouts more efficient, enjoyable, and safe.
Firstly, the display should prominently feature real - time workout data. This includes metrics such as speed, distance, calories burned, heart rate (if integrated with a heart rate monitor), and time. These data points are usually placed in the center or top section of the display, where they are easily visible to the user during exercise. For example, on a treadmill, the current speed and distance covered are typically displayed in large, bold fonts at the top of the touch screen, allowing users to quickly glance and monitor their progress without having to interrupt their running rhythm.
Secondly, control buttons for the equipment's functions should be intuitively arranged. Basic functions like starting, stopping, pausing, and adjusting the intensity level (e.g., speed on a treadmill, resistance on a stationary bike) should be easily accessible. These buttons are often placed along the edges or bottom of the display, where they can be reached with minimal hand movement. Some fitness equipment also features preset workout programs, and the selection buttons for these programs can be grouped together in a dedicated section, perhaps with icons representing different types of workouts (e.g., interval training, hill climbing) to make it easy for users to choose.
Another important aspect is the integration of multimedia and connectivity features. Many modern fitness equipment touch displays allow users to connect their smartphones or music players via Bluetooth or USB. The layout should include dedicated areas for controlling music playback, such as play, pause, skip, and volume buttons. Additionally, if the display supports video streaming or has a built - in entertainment system, there should be clear navigation buttons for accessing these features. For example, a touch display on a home gym machine might have a section for streaming workout videos from popular fitness apps, with easy - to - use controls for searching, selecting, and playing the videos.
User profile management is also a key function. The display should have options for users to create, save, and load their personal profiles. These profiles can store settings such as preferred workout intensity, saved workout programs, and user - specific data like weight and height for more accurate calorie calculation. The layout for profile management can include sections for entering personal information, viewing past workout history, and setting goals. For instance, a user can set a goal of burning a certain number of calories per week, and the display can show progress towards that goal over time.
